Automatic USB cable twisting tying machine for 8 shape

  • Model : SA-BJ8
  • Description: SA-BJ8 ,Automatic USB cable twisting tying machine for 8 shape, This machine suitable for automatic winding AC power cable, DC power core, USB data wire, video line, HDMI high-definition line and other transmission line, It’s Greatly Improved stripping speed and save labor cost
  • INQUIRY   EMAIL

Automatic USB cable twisting tying machine for 8 shape

This machine suitable for automatic winding AC power cable, DC power core, USB data wire, video line, HDMI high-definition line and other transmission line, It’s Greatly Improved stripping speed and save labor cost

Features:

1.Apply to single-end / double- ends ,AC power cord,DC power cord , Video line,HDMI ,USB wires

2.Auto and fast binding after Stepping on foot switch

3.Wire length(Head length, Tail length,Total binding length) ,  coil number,speed,quantity can be set .

4.Easy to operate

5.Save labor cost and improve output.

6.Adopted PLC program control , 7 inches touch screen for setting parameters.

7.Provide personalized customization according to different requirements.

Model

SA-BJ8

Finished Coil Type

ACDC cable Coil 8 shape

Available Wire Dia

≤Φ6.2mm

Available Length

≤ 6m

Winding Inner Dia

70-240mm

Reserved Head Length

≤100mm

Reserved Tail Length

≤500mm

Bundling Diameter

≤45mm

Production Rate

1800pcs/h

Air Connection

0.4-0.55 MPa

Power Supply

110/220VAC,50/60Hz

Dimensions

80*60*140cm
